Camera IP Zoom quay tốc độ cao VMGB-400

Camera IP Zoom

  • MS : VMGB-400
  • Bảo hành :
  • Kho hàng :
  • Hãng sản xuất : ACTi
  • Xuất xứ : TAIWAN
  • Seri sản phẩm :

Số lượng mua
Mua sản phẩm này
SP cùng loại
SP xem nhiều
Thông số kỹ thuật
Tổng quan
Video
Download
Phụ kiện



Product Type Metadata Camera
Maximum Resolution 2MP
Product Application Automatic License Plate Recognition
Application Environment Outdoor
Description Wide Angle Camera Built-in Deep learning-based ALPR with working for car speed <60km/h. (Available for cars in Taiwan)
Image Sensor Progressive Scan CMOS
Sensor Size 1/1.8 "
Day / Night Yes
Low Light Sensitivity Superior
Minimum Illumination Color: 0.001 lux at F1.2 (AGC on); B/W: 0.0003 (AGC on)
Mechanical IR Cut Filter Yes
IR LED Adaptive IR LED (850 nm)
IR Working Distance 50m
Electronic Shutter 1-1/100000 second (auto mode)

Lens


Focal Length Zoom, f2.8-12mm
Aperture F1.2-F2.5
Zoom Ratio 4.3x optical
Iris P-Iris
Focus Auto focus
Lens Mount Board mount
Horizontal Viewing Angle 107.3° - 39.8°
Vertical Viewing Angle 55.9° - 22.3°

Video


Compression H.265, H.264 (Baseline/ Main/ High profile), MJPEG
Maximum Frame Rate vs. Resolution 60 fps at 1920 x 1080
60 fps at 1280 x 720
30 fps at 704 x 480
30 fps at 640 x 480
Multi-Streaming Simultaneous 5 streams
Bit Rate 32Kbps - 16Mbps (per stream)
Wide Dynamic Range Extreme WDR (140 dB)
Image Enhancement Defogging, Digital Image Stabilizer (DIS, EIS)
Digital Noise Reduction 3D DNR
Built-in Analytics Automatic License Plate Recognition, Object Line Crossing Detection, Object Enter Area Detection
Image Orientation Rotation

Audio



Network


Ethernet Port 1 x Ethernet (10/100/1000 Base-T), RJ-45 connector

Video Analytics


Vehicle Type Cars
Analysis Source Type Video
Metadata Accuracy Good

Integration


ONVIF Compliant Yes, Profile S, Profile G
Supported Countries Taiwan

Interface


Analog Video Output 1 x CVBS, BNC connector
Local Storage MicroSD, MicroSDHC, MicroSDXC Memory Card Slot (bundled 64GB SD card; support for up to 256GB)
Digital Input/Output 2/2

General


Power Source DC 12V, PoE Class 4 (IEEE802.3at)
Power Consumption 16 W (DC), 18 W (PoE)
Weight 1920g (4.2lb)
Dimensions (Ø x L): 140mm x 351mm (5.5" x 13.8")
Environmental Casing Weatherproof (IP67), Vandal proof metal casing (IK10)
Heater Yes
Operating Temperature -40°C ~ 60°C (-40°F ~ 140°F)
Warranty 3 Year(s). For extended warranty offering, see http://www.acti.com/support/warranty

Dimension Diagram

Unit: mm [inch]
